Specifications
Aircraft
Weight 1.5Kg
Hover Accuracy Horizontal: ±1.5m
Vertical: ±0.5m
Max Pitch angle
20°
Maximum rate of climb/descent Climb: 5m/s
Descend: 2.5m/s
Maximum flight speed 16m/s
Max Distance (Geofence) 1000m
Flight time +/- 20min
Max Height 100m
Max lifting weight 450 grams
Max Wind Speed
*
10m/s, 20knots
.
Max Operating Temperature 40ºC
Min Operating Temperature -10ºC
Max Operating Altitude 4000m
UAV Dimensions 45CM X 45CM X 18CM
*<15knots recommended
Remote Control
Max
Transmission
Range
1000m
Battery 3.7v, 1600mAh
Frequency 2.4GHz
Transmitter Power ≤27dBm
Power 0.5W
Battery
Voltage 11.1v
Capacity 6800mAh
Type LiPo
Energy 75.48Wh
Operating
Temperature
-
10ºC
-
40ºC
Charger
Voltage Output 12.6V
Power 4A
Newton 3 Release
Tension release ≥ 1.1kg
Mechanical Release Pilot operated release
