BC 2000 DIGITAL
Audio Routing, Mixing and Processing System for Program Production Centers
HARDWARE MANUAL
89
TITAN technical characteristics.
External synchronism: AES11.
GPI inputs:
- Inputs protected by optocoupler (4N35).
- Maximum input current: 60 mA.
- A voltage ranging between 5 V and 30 V will be applied.
GPO outputs:
- By bistable relay (contact closing).
- Maximum current: 1 A @ 30 V DC, 0.5 A @ 125 V AC.
- Maximum voltage: 110 V DC or 125 V AC.
- Maximum power: 30 W, 62.5 VA.
Optical fiber interface:
- Type: SFP (Small Form Pluggable). Package style duplex LC.
- Nominal range:
• 150 meters for 62.5/125µm MULTIMODE fiber (MMF).
• 300 meters for 50/125µm MULTIMODE fiber (MMF).
• >10 Km for 1310nm MONOMODE fiber (SMF).
- Transmission: LED, 850 nm.
Power supplies:
- 2 redundant power supplies, working in parallel mode with independent inputs.
- Input voltage: from 90 to 250 VAC, 50/60Hz.
- Output voltage: 48 volts DC.
- Maximum power: 40VA per module.
General characteristics.
- Approximate consumption: 28 watts.
- Height: 1U.
- Depth: 320 mm.
Characteristics are subject to change without notice.
