AEQ BC-2500 User Manual

AEQ BC-2500
Radio Broadcast Mixing Desk
25
5.6.2. Description of Controls and Connectors.
NETWORK
LEVEL
BYPASS
NETWOR
K
PFL
NETWORK
5
4
3
2
1
1.- Bypass input level potentiometer NETWORK LEVEL
2.- Bypass/Console selector BYPASS NETWORK
3.- Luminous bypass pre-listen indicator PFL NETWORK
4.- Pre-listen activation push-button PFL NETWORK
5.- Output level slide potentiometer FADER
6.- Mono line output connector MONO OUTPUT
7.- Left line output connector OUTPUT (L)
8.- Rigth line output connector OUTPUT (R)
9.- Left external input connector EXT INPUT (L)
10.- Rigth external input connector EXT INPUT (R)
6
7
8
9
10
FRONT
REAR

AEQ BC-2500 Specifications

General

Brand	AEQ
Model	BC-2500
Category	Music Mixer
Language	English
