AEQ BC-2500 User Manual

AEQ BC-2500
Radio Broadcast Mixing Desk
44
7.3. BC-2521/22 programming bridges.
Send to AUX 1L POSTFADER:......................... P.D.P. 1 On & P.D.P. 2 Off
Send to AUX 1R POSTFADER:......................... P.D.P. 3 On & P.D.P. 4 Off
Send to AUX 1L PREFADER:............................ P.D.P. 2 On & P.D.P. 1 Off
Send to AUX 1R PREFADER:.…........................ P.D.P. 4 On & P.D.P. 3 Off
Send to AUX 2L POSTFADER:...............…........ P.D.P. 5 On & P.D.P. 6 Off
Send to AUX 2R POSTFADER:......................... P.D.P. 7 On & P.D.P. 8 Off
Send to AUX 2L PREFADER:............................ P.D.P. 6 On & P.D.P. 5 Off
Send to AUX 2L PREFADER:............................ P.D.P. 8 On & P.D.P. 7 Off
Activation of PFL REMOTE:.......................... P.D.P. 9 On
Deactivation of PFL REMOTE:..................... P.D.P. 9 Off
Activation of the signal circuit and
cut the CONTROL zone:......................... P.D.P. 10 On
Deactivation of the signal circuit and
cut the CONTROL zone:......................... P.D.P. 10 Off
Activation of the signal circuit and
cut the STUDIO zone:.......................... P.D.P. 11 On
Deactivation of the signal circuit and
cut the STUDIO zone:.......................... P.D.P. 11 Off
Activation the MUTE REMOTE :....................... P.D.P. 12 On
Deactivation the MUTE REMOTE:................. P.D.P. 12 Off
REMOTE A output when
the contacts are open:.................................. P.D.P. 13 On & P.D.P. 14 Off
REMOTE A output when
the contacts are closed:........................................... P.D.P. 14 On & P.D.P. 13 Off
REMOTE B output when
the contacts are open:.................................. P.D.P. 15 On & P.D.P. 16 Off
REMOTE B output when
the contacts are closed :........................................... P.D.P. 16 On & P.D.P. 15 Off
The send is activated when the switch
CHANNEL ON and FADER are activated.:... P.D.P. 17-18 On in position 1C
The send is only activated when the
CHANNEL ON is activated.:.......................... P.D.P. 17-18 On in position 2C
The send is always activated
independent of the CHANNEL ON switch
and the FADER.:...... P.D.P. 17-18 On in position 3C
Send to BUS PHONE 2 :.................................... P.D.P. 19 On
FUNCTION P.D.P. position for
function activation
On Bridge installed
Off Bridge not installed
0 0
0 0
