AEQ BC-2500 User Manual

AEQ BC-2500
Radio Broadcast Mixing Desk
53
7.9. BC-2578 programming bridges
T’Back microphone send from T’Back selector to MASTER 1: P.D.P. 1,2,3 & 4. On.
T’Back microphone send from T’Back selector to MASTER 2:. P.D.P. 5,6,7 & 8. On.
T’Back microphone send from T’Back selector to AUXILIARY 1: P.D.P. 9,10,11 & 12. On.
T’Back microphone send from T’Back selector to AUXILIARY 2: P.D.P. 13,14,15 & 16. On.
Time-Top’s input signal send
to MASTER 1 output :.............................................................. P.D.P. 17,18,19 & 20.
On.
Time-Top’s input signal send
to MASTER 2 output...................................................... P.D.P. 21,22,23 & 24.
On.
Time-Top’s input signal send
to AUXILIARY 1 output....................................................... P.D.P. 25,26,27 & 28. On.
Time-Top’s input signal send
to AUXILIARY 2:output............................................................. P.D.P. 29,30,31 & 32.
On.
Oscillator output tone send to PHONE 2
output when sending to the PHONE output.:...............................P.D.P. 33. On.
Talk-Back microphone send from the output PHONE 2
when sending to the PHONE output.:........................................ P.D.P. 34. On.
Console with PHONE 1 installed.................................................P.D.P. 35. Off
Console without PHONE 1 installed ...........................................P.D.P. 35 On
Console with PHONE 2 installed.................................................P.D.P. 36. Off
Console without PHONE 2 installed............................................P.D.P. 36 On
FUNCTION
P.D.P. position for
function activation
On Bridge installed
Off Bridge not installed
0 0
0 0
