AEQ BC-2500 User Manual

AEQ BC-2500
Radio Broadcast Mixing Desk
55
7.10. Position of the BC-2578 module programming bridges
BC-2578 module
(I.C. board view)
P.D.P. defect position
On Bridge installed
Off Bridge not installed
0 0
0 0
P.D.P.1 On
P.D.P.2 On
P.D.P.3 On
P.D.P.4 On
P.D.P.5 On
P.D.P.6 On
P.D.P.7 On
P.D.P.8 On
P.D.P.9 On
P.D.P.10 On
P.D.P.11 On
P.D.P.12 On
P.D.P.13 On
P.D.P.14 On
P.D.P.15 On
P.D.P.16 On
P.D.P.17 On
P.D.P.18 On
P.D.P.19 On
P.D.P.20 On
P.D.P.21 Off
P.D.P.22 Off
P.D.P.23 Off
P.D.P.24 Off
P.D.P.25 Off
P.D.P.26 Off
P.D.P.27 Off
P.D.P.28 Off
P.D.P.29 Off
P.D.P.30 Off
P.D.P.31 Off
P.D.P.32 Off
P.D.P.33 On
P.D.P.34 On
1,2,3,4,5,6,7,8,9,
10,11,12,13,14,151
6,17,18,19,20,2122,
23,24,25,26,2728,2
9,30,31,32
33,34
