23
Thermostat Indicates the current thermostat settings (paragraph 7.7)
O
Cool
Heat
Other thermal Indicates the status of the additional heat source (paragraph 7.8)
On
O
2-way valve Indicates the status of the 2-way valve on the system
On
O
HP-Antifree Indicates the status of the anti-freeze protection
On
O
Gate-Ctrl Indicates the status of the external contact (paragraph 7.15)
Card in
Card out
4-way valve Indicates the status of the 4-way valve on the unit
On
O
Disinfection Indicates the current status of the anti-legionella cycle (paragraph 4.10)
O
Progess
Done
Error
Flow switch Indicates the current status of the ow switch on the unit
On
O
These pages display the current values for the unit's operating parameters. After accessing the "Param-
eters" function, you can browse the various pages using the buttons on the left and right sides of the
window. The following table shows the information available.
6.3. Viewing the status of the unit parameters (Parameter)
NB: all information contained in this menu is "read only".
Label Meaning
T-outdoor Indicates the external air temperature detected by the unit
T-suction Indicates the temperature on the compressor inlet
T-discharge Indicates the compressor delivery temperature
T-Defrost Indicates the temperature for the defrosting cycle
T-water in PE Indicates the temperature of the water entering the plate heat exchanger
T-water out PE Indicates the temperature of the water leaving the plate heat exchanger
T-optional water sen. Indicates the temperature of the water leaving the optional heater (paragraph 7.9)
T-tank ctrl.
Indicates the temperature measured in the compatible Aermec accessory tank
T-economizer in Indicates the temperature on the economiser inlet
T-economizer out Indicates the temperature on the economiser outlet
T-oor debug Indicates the set temperature for radiant oor debug (paragraph 7.12)
Debug time Indicates the set time for radiant oor debug (paragraph 7.12)
T-gas pipe Indicates the temperature detected on the gas side of the cooling circuit
T-liquid pipe Indicates the temperature detected on the liquid side of the cooling circuit
T-auto mode
Indicates the current set-point temperature, calculated using the climatic curve
(paragraph 4.7)
T-remote room Indicates the room temperature detected by the probe (paragraph 7.10)
Dis. pressure Indicates the compressor delivery pressure value
