AERMEC HMI Series - Control Logic Setting

25
To navigate the “Function” or “Parameter“ sub-menu,
use the following keys:
• (
1
) Move back to the previous page
• (
2
) Move on to the next page
• (
3
) Go back to the higher level menu
• (
4
) Go back to the main page
• To access a function, click on the text of that
function.
Function (1/4)
Ctrl. state: T water out
Cool 2 way valve: On
Heat 2 way valve: Off
Solar setting: Without
Water tank: With
3 4
1
2
Parameter (1/1)
T HP max: 50°C
Cool run time: 5 min
Heat run time: 3 min
3 4
1
2
NB: if the relative function is activated (paragraph 8.3), the value of these parameters will be stored in the
memory and automatically reset after any possible voltage failure.
After accessing the “Ctrl.state” function, you can
choose whether to base the unit control logic on the
processed water temperature or on the ambient air
temperature (if the air probe accessory is installed
and correctly set). Select the required logic, then press
“OK” to confirm.
Ctrl. state
T room
T water out
OK Cancel
NOTES:
1. If the ambient air probe accessory is not installed (and correctly set), you can only choose “T-water
out”.
2. If the relative function is activated (paragraph 8.3), the value of these parameters will be stored in the
memory and automatically reset after any possible voltage failure.
7.2. Setting the control logic (Ctrl.state)
