AutoTest Sytem Operation
Subject to Export Control, see Cover Page for details.
5-2
Soft Key Definitions
[Start] Soft Key
Initiates selected AutoTest Script. An AutoTest script is selected by pressing the [Script] Soft
Key. Refer to section titled Running an AutoTest Script for information on using this feature
[Script] Soft Key
Opens soft key sub-menu that allows user to load AutoTest script files. Refer to section titled
Running an AutoTest Script
for information on using this feature.
[Load] Soft Key
Loads selected script file.
[On Error (ABORT)] Soft Key
Allows user to define AutoTest behaves if a test fails. Behavior options are:
● Ignore (i.e. the fail is counted and displayed, but the run continues),
● Abort (i.e. the run halts), or
● Pause (the operator can decide whether or not to continue).
Setting should be defined before starting AutoTest script.
[Results] Soft Key
Opens a soft key sub-menu that provides user with the ability to Print, Save, Recall or Delete
test results. Refer to section titled Storing Results
for information on saving test results.
Creating an AutoTest Script
AutoTest allows users to transfer unformatted script text files to the 3900 from a USB memory stick or
floppy disk.
A formatted script file is imported into the Test Set via the following UTILS, File Management Tile
feature. Use the following key sequence to import a data file:
UTILS/File Management/AutoTest/Scripts/Import
Do not apply any formatting (such as font selection) to file.
The Test Set requires that AutoTest script files end with *.ats.
Refer to the following sections for additional information on creating AutoTest Scripts and AutoTest
Script content:
Common Script Elements
Script Structure
Sample Script
(System) Command Elements
