60
4. Another view of the tank installed shown below
5. Route the vent line on top of the fuel tank and
secure with small nylon ties as shown. This
will stop excess fuel from draining out the
vent line during an extended down line or
when lifting the tail.
6. Route fuel line through firewall and connect to
the engine carburetor as shown Use nylon tie to
secure
Filler Dot and Vent Exit Line
Installation
1. Gather the fuel filler dot and drill bits as shown
below.
Note: We recommend you start with a smaller size
drill bit then increase the bit size to the
correct size to fit your filler dot. This will
help prevent the fuse side from splitting
or cracking.
