22 Aeroworks 30cc Freestyle Extra 260 Assembly Manual
4. Mount the tail wheel steering tiller using two
wood screws.
2. Align rudder tiller steering arm with pre drilled
mounting holes at bottom of rudder.
3. Apply a drop of thick CA to the tiller arm
mounting screws before inserting in the pre-
drilled holes.
5. Align the tail wheel with pre drilled mounting
holes on the bottom of the fuse.
6. Place a drop of thick CA on tail wheel strut
mounting screws before inserting in the pre-
drilled mounting holes on the bottom rear of the
fuse.
7. Mount the tail wheel struts using three wood
screws.
