Aeroworks 30cc Freestyle Extra 260 Assembly Manual 23
10. Repeat spring installation steps for the remaining
tail wheel spring. Ensure that the springs allow
for full rudder deflection and that they do not
bind.
8. Attach the steering spring to the rudder tiller.
Center the spring between both tail wheel and
steering tillers.
9. Wrap spring around steering tiller and then back
around itself as show below. This is best per-
formed by hand but pliers can also be used.
