Aeroworks 30cc Freestyle Extra 260 Assembly Manual 35
8. Gather the fuel filler dot, vent exit dot and hobby
knife as shown below.
9. Mark location of fuel filler dot.
Builders Tip:
In order to prevent the fuel from siphoning out of the
tank place fuel dot higher than the clunk line of the
fuel tank.
10. Use a hobby knife to remove covering followed
by the underlying balsa as shown below. The use
of a new blade is recommended for a clean, easy
cut.
11. Use thick CA to secure fuel dot in fuse.
12. Feed filler line through dot and plug line into
filler plug as shown.
13. Apply a small amount of petroleum jelly to the
end of the fuel line. This will allow it to plug
into the fuel dot easily.
