AES Prime 6E - System Wiring Connections; Call Station and Power Connections; Main External Connections

P a g e | 5
Call Station and Power Connections
+
-
+
-
+
-
-
+
Main External Connections
Relay1
Auto Gates
Other
device, e.g.
exit button
Separate
power
supply
Magnetic lock
on small gate
or door
+12v
0V
Call Station
OUT
2
1
KPAD/PROX
Module
+24v DC IN
0v DC IN
0V
+24V
IN
1
2
24Vdc
0V
Slave IN
Use Screened CAT5 for audio &
connect screen wire to 0V!
Relay2
COM
N/O
COM
N/C
