54 Maintenance - Periodic Maintenance
Replace the Conveyor Belt if necessary.
Performed by Service Engineer.
Part # : D2+2503028
4.5 Weekend Maintenance.
(Performed at the end of every week; engine sitting idle for 2 – 4 days).
Performa‘HeadFlush’onalltheprintheads.
Open the Home Cover.
Switchthe2-wayinkvalvesforBlack&Cyanto‘S’position.
Openthesolution2-wayvalve(to‘S’position).
Push onto the Flush button (on the rear side of the carriage) with intervals >>> 1
second ON and 4 seconds OFF >>> till you see the cleaning solution coming out
of Black & Cyan print heads.
Switchthe2-wayinkvalvesforBlack&Cyanbackto‘I’position.
Repeat this sequence for Magenta & Yellow print heads.
Now, switchallthefour2-wayinkvalvesto‘S’positionandpresstheFlushbut-
ton for 1 second (cleaning all the print heads at one time).
ClosetheSolution2-wayvalve(backto‘I’position).
Clean the residue of the cleaning solution on the print heads (just a gentle tap)
and clean the base plate.
Turn the Vacuum Gauge to zero.
Push the Red Emergency Button.
TurnthePowerSwitch‘OFF’ (from rear side of the Anapurna).
At Restart (start of the working week):
Power Switchto‘ON’position
Turn out the Emergency Button & power-on the engine (pressing START)
Wait till the base plate temperature reaches 49° C.
Open the Home Cover
Turn the Vacuum gauge to restore the negative vacuum to approx -.036
Switchallthe2-wayinkvalvesto‘I’position,leavethesolutionvalveat‘I’
Perform a Long Purge (with intervals of 2 seconds ON and 4 seconds OFF) till ink
is coming out of the print heads
Take a new lint free cloth and clean the ink residue from the print heads (just a
gentle tap, no wiping)
Perform a PRIME TEST to check the print heads
4.6 Long Stand Still Preparation / Maintenance
(Engine sitting idle for more than 14 days)
Follow“Performa‘Head Flush’ on all the print heads” procedures as discussed
above in weekend maintenance (do not turn the engine OFF)
Open the Capping Cover & clean the capping station
Press CAPPING from the control panel; the carriage will start going up, move
towards the left side (capping side) & move down on the caps
Push the red Emergency Button
Turn the PowerSwitch‘OFF’(fromrearsideoftheAnapurna)
At Restart (start of the working week):
PowerSwitchto‘ON’position
Turn out the Emergency Button & power-on the engine (pressing START)































