Stay ahead. With Agfa Global Services. :Anapurna M4F - Operator Manual
Information - Printer overview 9
2. Printer overview.
2.1 Front view, parts & locations.
The roll to roll system is optional for the :Anapurna M4f
and is not delivered with a standard system.
2.2 Home view, parts & locations.
EMERGENCY Stop UV LAMP R-L Switch LCD Operation Panel
Start Button
Sub Ink Tank Temp. Head Base Temp.
Vacuum Switch
Capping Cover Switch
Media Set
