XD 14, XD⁺14
1 2 3 4 5 6 7 8
44
1.
Power button with indicator light
• Press to start the DR detector or to display the status of the DR
detector.
• Press and hold for 3 seconds to stop the DR detector.
2.
AP mode button
• Press to display the status of the DR detector.
• Press and hold for 3 seconds to change the network connection.
3.
Status display
• Battery status
• Connection status
• IP address
• SSID name
4.
Antenna of the wireless network adapter
Operation in wireless configuration.
5.
Battery status indicator
6.
Connector for power adapter (USB Type-C)
7.
DR detector connector
• Operation in wired configuration.
• Charging the battery.
8.
Effective imaging area border and center position indication
Figure 2: DR detector operation controls
