1.
Knobs securing the battery cover plate.
2.
Cover plate for the DR detector battery
The battery supplies power to the detector during wireless
communication.
Figure 3: DR detector rear side
Related Links
Advanced Operating on page 97
XD 14, XD
⁺
14 technical data on page 123
20 | XD 14, XD⁺14 | Introduction to the DR Detector
0430A EN 20210426 1355
