Agilent 1260 Infinity II Preparative Autosampler User Manual 193
Parts and Materials for Maintenance
10
Drawer Assembly
Figure 24 Drawer-Kit 100 x 2 mL Vials Classic
1 Drawer for 50 x 2 mL Vials Classic Left
2 Drawer for 50 x 2 mL Vials Classic Right
It is required that all drawers are put into correct positions, that is, classical drawer 1-50
must be on the left side and classical drawer 51-100 on the right side.
