32 Agilent 1260 Infinity II Preparative Autosampler User Manual
2
Site Requirements and Specifications
Specifications of the Sample Cooler
Specifications of the Sample Cooler
Cooling unit is designed as vapor-compression refrigeration system. Contains
fluorinated greenhouse gas (refrigerant) according to the Kyoto protocol. For
specifications of refrigerant, charge capacity, carbon dioxide equivalent
(CDE), and global warming potential (GWP) see instrument label.
Table 3 Physical Specification of the Sample Cooler
Type Specification Comments
Weight < 6 kg
Dimensions
(height × width × depth)
205mm x 340mm x 370mm
Refrigerant gas HFC-134a (0.042 kg) Ozone depletion
potential (ODP) = 0
Supply voltage 24 VDC (nominal)
Current 10 A max.
Ambient operating temperature 4 – 40 ° C (39.2 – 104 ° F)
Ambient non-operating
temperature
-40 – 70 ° C (-20 – 158 ° F)
Operating altitude Up to 3000 m (9842 ft)
Non-operating altitude Up to 4600 m (15091 ft)
Safety standards:
IEC, EN, CSA, UL
Installation category II,
Pollution degree 2
For indoor use only.
ISM Classification ISM Group 1 Class B According to CISPR 11
