222 Agilent 1260 Infinity II Preparative Autosampler User Manual
12
Hardware Information
Interfaces
ERI Description
The ERI interface contains eight individual programmable input/output pins.
In addition, it provides 24 V power and 5 V power and a serial data line to
detect and recognize further add-ons that could be connected to this interface.
This way the interface can support various additional devices like sensors,
triggers (in and out) and small controllers, etc.
Figure 29 Location of the ERI interface (example shows a G7114A/B VWD)
