Installing Logic Analyzer Cards and Probes 2
16900 Series Logic Analysis Systems Installation Guide 59
16760A Logic Analyzer (2-card module)
Use two 2 x 10 cables and two 2 x 40 cables (in the accessory pouch) to
connect the modules.
Turn off the mainframe power before removing, replacing, or installing modules following
the procedures on page 26.
