14
Chapter 1: General Information
Recommended Test Equipment
Equipment Critical Specification Recommended Model/Part Use†
Flying Lead Probe Set
(Qty 2)
No substitute Agilent E5382A P, T
Ground Clips
(Qty 10)
No substitute 16517-82105 (pkg of 20)
(Included with E5382A Probe Set)
T
Stimulus Board No substitute 16760-60001 T
Pulse Generator ≥ 310 MHz, two channels, differential
outputs, 150-180 ps rise/fall time (if
faster, use transition time converters)
Agilent or HP 8133A Option 003 P, T
150 ps Transition Time
Converter
(Qty 4)
Required if pulse generator’s rise time is
less than 150 ps. (Pulse generator
conditions: Voffset=1V, ∆V=250 mV.)
Required for 8133A opt. 003.
Agilent or HP 15435A P
Oscilloscope Bandwidth ≥ 1.5 GHz,
sampling rate ≥ 8 GSa/s
Agilent or HP 54845A or 54845B P
SMA Coax Cable
(Qty 2)
>18 GHz bandwidth Agilent or HP 8120-4948 P
Male BNC to Female
SMA Adapters
(Qty 2)
>18 GHz bandwidth Cambridge Products CP-AD507
(see www.cambridgeproducts.com)
P
SMA/Flying Lead Test
Connectors, (f) SMA to (f)
SMA to Flying Lead Probe
(Qty 4)
No substitute See “Assemble the SMA/Flying Lead
Test Connectors” on page 23
P
† P = Performance Tests, T = Troubleshooting
