Chapter 4: Calibrating

Calibration Strategy

The 16753/54/55/56A or 16950A logic analyzer does not require a periodic

operational accuracy calibration. To test the module against the module

specifications, refer to

the “Testing Logic Analyzer Performance” chapter on

page 19.
