78
Chapter 3: Testing Logic Analyzer Performance
Test Pod 2 in 300 Mb/s Mode
threshold window select Differential.
a Select Close to close the K threshold window. Select Close to close the
Clock Thresholds window.
12 Re-establish the trigger function:
a In the logic analyzer’s Setup and Trigger window, select the Trigger tab,
and the Trigger Functions subtab.
b Select “Find pattern n times” and select the “Replace” button.
c Enter “A” in the “Label 1 = “ field.
13 Adjust the sampling positions using Eye Finder. Be sure to expand “Label1
(4 channels)” and use the recommended starting position noted on page
68. Realign any stray channels if necessary. See page 69.
14 Determine pass or fail (1 of 2 tests). See page 71.
15 Ensure that the Listing window is set up. See page 71.
16 Select the Run Repetitive icon in the Listing window.
17 Determine pass or fail (2 of 2 tests). See page 73.
Test the complement of the bits (Pod 2, 300 Mb/s mode)
1 Test the complement of the bits. See page 75.
