Chapter 3: Testing Logic Analyzer Performance
Assemble the SMA/Flying Lead Test Connectors
2 Solder the pin strip to the SMA board mount connector:
a Solder the leads on the left side of the pin strip to the center conductor
of the SMA connector as shown in the diagram below.
b Solder the leads on the right side of the pin strip to the inside of the
SMA connector’s frame as shown in the diagram below. Use a small
amount of solder.
3 Attach the second SMA board mount connector:
a Re-heat the solder connection made in the previous step, and attach
the second SMA connector, as shown in the diagram below. Note that
the second SMA connector is upside-down, compared to the first. Add a
little solder to make a good connection.
b Solder the center conductor of the second SMA connector to the center
conductor of the first SMA connector and the leads on the left side of
the pin strip.
solder
