Chapter 3: Testing Logic Analyzer Performance
Test Pod 1 in 300 Mb/s Mode
See page 35 for details.
6 Adjust the sampling positions (run Eye Finder). See page 43.
7 Determine pass or fail (1 of 2 tests). See page 46.
8 Switch to the Listing window by selecting the Listing tab at the bottom of
the main logic analyzer window.
9 Select the Run Repetitive icon .
10 Determine pass or fail (2 of 2 tests). See page 48.
