Installing Pattern Generator Cards 3
16900 Series Logic Analysis Systems Installation Guide 73
16720A Pattern Generator (3-card module)
Use three 2 x 10 cables to connect the modules.
NOTE
Turn off the mainframe power before removing, replacing, or installing modules. For
instructions on installing modules into the logic analysis system frame, refer to page 26.
Expander
Master
Expander
2x10 Cable
