Agilent Technologies 240 Series AA - Zeeman Instrument Back View

Introduction
Agilent 240/280 Series AA (including Zeeman) 31
Zeeman instrument back view
Where:
1. Accessories serial port, such as the GTA
Viewing/Fume Extraction accessory
8. GTA 120 power cable
2. USB camera cable port
9. GTA 120 fuses
3. AA instrument IEEE 488 cable port
10. Water in
4. Power cable
11. Water out
5. UltrAA lamp option port
12. Alternate gas inlet, typically nitrogen
or air
6. UltrAA accessory and fuses
13. Normal gas inlet, typically argon
7. Air purge port
14. GTA 120 IEEE 488 cable port
1
2
3
7
5
6 8 9
10
11
12
13
14
4
