Introduction
34 Agilent 240/280 Series AA (including Zeeman)
Agilent AA documentation
This manual covers the installation of the Agilent SpectrAA software for 240/280
series AA instruments. Instructions for installing, operating, and maintaining the
instruments and components are included in the SpectrAA Help (see Page 51).
Operating instructions for the Sample Introduction Pump System (SIPS) and other
AA accessories are given in the manuals accompanying the accessories or in the
SpectrAA Help
Conventions
The following conventions have been used throughout this manual:
Single quotes (‘ ’) indicate a selection that you can make from several choices,
such as radio buttons, checkboxes, and software items.
ALL CAPITALS indicates text that you must type in from the keyboard (for
example, type SETUP at the prompt).
Electrical Connections
Rear of instrument:
IEEE 488
Accessory, 9-way female D-range type
Accessory, MCA, 6-way DIN type (AA280FS and AA280Z only)
USB port, optional
UltrAA lamp connections: Burndy circular 6-way, optional (actual number
depends on the model and option selected)
WARNING
Shock Hazard
High voltage
– To maintain safety, only the UltrAA lamp power supplies should
be used at these connections.
Some pins will become energized (300 VDC) when an UltrAA lamp is in a
matching socket. To avoid death or electric shock, NEVER touch any exposed
pins.
Certaines broches du culot des lampes sont sous tension (300 VCC) à la mise
en place d’une UltrAA lampe. Pour éviter l’électrocution ou la mort, ne jamais
toucher les broches sous tension.
