Introduction
Agilent 240/280 Series AA (including Zeeman) 35
Front of instrument:
 Zeeman workhead CPC 14 way connection behind the left cover (Zeeman
only).
WARNING
Shock Hazard
To prevent connector damage, switch OFF the instrument before inserting
the plug and always turn the locknut fully clockwise to the detent position.
To maintain safety, only the Zeeman workhead connector should be used
at this connection.
Lamp bay:
 Deuterium lamp:
Molex 3-way connection, in lamp compartment (behind lamp panel in lamp
compartment on 240/280 series AA instruments).
WARNING
Shock Hazard
To maintain safety, only the deuterium lamp should be used at these
connections.
 Hollow cathode lamps:
 Four lamp capacity on the 240 series AA
 Eight lamp capacity on the 280 series AA
WARNING
Shock Hazard
High voltage – To maintain safety, only hollow cathode lamps should be
used at these connections.
Fuses
CAUTION
For continued protection against fire hazard replace fuse only with same type
and rating.
