154
Chapter 7 Replaceable Parts
33250-66511 – Main PC Assembly (A1)
7
C622 0160-7061 CAP-FXD 2200pF 50 V 02010 08055C222KAT
C623 0160-7736 CAP-FXD 1uF +-10% 16 V CER X7S 06352 C3216X7R1C105K
C624 0160-7798 CAP 0.1UF 50V 10% X7R 0805 06352 C2012X7R1H104K
C625 0160-7736 CAP-FXD 1uF +-10% 16 V CER X7S 06352 C3216X7R1C105K
C626 0160-5945 C MLYS .01U 50V CAP. 02010 08055C103KAT A
C627 0160-7798 CAP 0.1UF 50V 10% X7R 0805 06352 C2012X7R1H104K
C628 0160-6444 3 CAP-FXD 0.022uF 50 V 02010 08055C223KAT
C629 0160-7061 CAP-FXD 2200pF 50 V 02010 08055C222KAT
C630 0160-7798 CAP 0.1UF 50V 10% X7R 0805 06352 C2012X7R1H104K
C631 - C632 0160-7736 CAP-FXD 1uF +-10% 16 V CER X7S 06352 C3216X7R1C105K
C701 - C703 0160-7798 CAP 0.1UF 50V 10% X7R 0805 06352 C2012X7R1H104K
C704 0160-7736 CAP-FXD 1uF +-10% 16 V CER X7S 06352 C3216X7R1C105K
C705 0160-5945 C MLYS .01U 50V CAP. 02010 08055C103KAT A
C706 0160-5975 4 CAP-FXD 10pF 50 V 02010 08055A100JAT A
C707 0160-7798 CAP 0.1UF 50V 10% X7R 0805 06352 C2012X7R1H104K
C708 0160-7736 CAP-FXD 1uF +-10% 16 V CER X7S 06352 C3216X7R1C105K
C709 - C718 0160-7798 CAP 0.1UF 50V 10% X7R 0805 06352 C2012X7R1H104K
C801 0180-4758 2 CAP-FXD 47uF +-20% 20 V TA 12340 T491D476M020AS
C802 - C804 0160-7736 CAP-FXD 1uF +-10% 16 V CER X7S 06352 C3216X7R1C105K
C805 0180-4577 CAP-FXD 10uF +-20% 10 V TA 12340 T491B106M010AS
C806 - C808 0160-7798 CAP 0.1UF 50V 10% X7R 0805 06352 C2012X7R1H104K
C809 0160-5967 9 CF 100PF 5% 06352 C2012COG1H101J
C810 0160-7798 CAP 0.1UF 50V 10% X7R 0805 06352 C2012X7R1H104K
C811 0160-7708 19 CAP 1000pF 50 V 02010 08055A102JATRA
C812 - C813 0160-7798 CAP 0.1UF 50V 10% X7R 0805 06352 C2012X7R1H104K
C814 0160-5945 C MLYS .01U 50V CAP. 02010 08055C103KAT A
C815 0160-7736 CAP-FXD 1uF +-10% 16 V CER X7S 06352 C3216X7R1C105K
C816 0160-7798 CAP 0.1UF 50V 10% X7R 0805 06352 C2012X7R1H104K
C817 0160-7757 5 CAP-FXD 47pF +-1% 50 V CER C0G 02010 08055A470FATMA
C901 0160-7736 CAP-FXD 1uF +-10% 16 V CER X7S 06352 C3216X7R1C105K
C902 0160-5945 C MLYS .01U 50V CAP. 02010 08055C103KAT A
C903 0160-5958 1 CAP-FXD 39pF +-5% 50 V CER C0G 02010 08055A390JAT A
C904 0160-5947 CAP-FXD 1000pF 50 V 02010 08055C102KAT A
C905 0160-7798 CAP 0.1UF 50V 10% X7R 0805 06352 C2012X7R1H104K
C906 0160-5967 CF 100PF 5% 06352 C2012COG1H101J
C907 0160-7911 CAP-FXD 4700pF +-1% 50 V CER C0G 12340 C1206C472F5GAC
C908 0160-5950 CAP-FXD 470pF 50 V 02010 08055A471JAT A
C909 0160-5947 CAP-FXD 1000pF 50 V 02010 08055C102KAT A
C911 0160-8361 CAP 0.22UF 25 V 06352 C2012X7R1E224K
C912 0160-7736 CAP-FXD 1uF +-10% 16 V CER X7S 06352 C3216X7R1C105K
C913 0160-5945 C MLYS .01U 50V CAP. 02010 08055C103KAT A
C914 0160-7708 CAP 1000pF 50 V 02010 08055A102JATRA
C915 - C917 0160-7798 CAP 0.1UF 50V 10% X7R 0805 06352 C2012X7R1H104K
C918 0160-5945 C MLYS .01U 50V CAP. 02010 08055C103KAT A
C919 0160-6982 1 CAP-FXD 0.033uF 50 V 02010 08055C333KAT_A
Reference
Designator
Agilent Part
Number
Qty Part Description
Mfr.
Code
Mfr. Part Number
To Next Page
