155
Chapter 7 Replaceable Parts
33250-66511 – Main PC Assembly (A1)
4
7
C920 0160-5945 C MLYS .01U 50V CAP. 02010 08055C103KAT A
C921 0160-7707 2 CAP-FXD 0.47uF +-10% 16 V CER X7R 06352 C3216X7R1C474K
C922 - C923 0160-7798 CAP 0.1UF 50V 10% X7R 0805 06352 C2012X7R1H104K
C924 - C925 0160-5945 C MLYS .01U 50V CAP. 02010 08055C103KAT A
C926 0160-7798 CAP 0.1UF 50V 10% X7R 0805 06352 C2012X7R1H104K
C1001 - C1002 0160-7798 CAP 0.1UF 50V 10% X7R 0805 06352 C2012X7R1H104K
C1003 0160-5947 CAP-FXD 1000pF 50 V 02010 08055C102KAT A
C1004 - C1005 0160-7798 CAP 0.1UF 50V 10% X7R 0805 06352 C2012X7R1H104K
C1006 0160-5957 CAP-FXD 47pF +-5% 50 V CER C0G 02010 08055A470JAT A
C1007 0160-7721 1 CAP-FXD 82pF +-1% 50 V CER C0G 02010 08055A820FATMA
C1008 0160-7708 CAP 1000pF 50 V 02010 08055A102JATRA
C1009 0160-7736 CAP-FXD 1uF +-10% 16 V CER X7S 06352 C3216X7R1C105K
C1010 0160-5945 C MLYS .01U 50V CAP. 02010 08055C103KAT A
C1011 0160-7736 CAP-FXD 1uF +-10% 16 V CER X7S 06352 C3216X7R1C105K
C1012 0160-7798 CAP 0.1UF 50V 10% X7R 0805 06352 C2012X7R1H104K
C1013 0160-5952 4 CAP-FXD 330pF +-5% 50 V CER C0G 02010 08055A331JAT A
C1014 0160-5967 9 CF 100PF 5% 06352 C2012COG1H101J
C1015- C1017 0160-7798 CAP 0.1UF 50V 10% X7R 0805 06352 C2012X7R1H104K
C1018 - C1019 0160-5944 15 CAP-FXD 0.047uF +-10% 50 V CER X7R 02010 08055C473KAT A
C1020 - C1025 0160-7798 CAP 0.1UF 50V 10% X7R 0805 06352 C2012X7R1H104K
C1101 0160-5967 CF 100PF 5% 06352 C2012COG1H101J
C1102 0160-5945 C MLYS .01U 50V CAP. 02010 08055C103KAT A
C1103 0160-5963 1 CAP-FXD 18pF 50 V 02010 08055A180JAT A
C1104 0160-5955 2 CAP-FXD 68pF +-5% 50 V CER C0G 02010 08055A680JATRA
C1105 0160-7798 CAP 0.1UF 50V 10% X7R 0805 06352 C2012X7R1H104K
C1106 0160-7736 CAP-FXD 1uF +-10% 16 V CER X7S 06352 C3216X7R1C105K
C1107 0160-7798 CAP 0.1UF 50V 10% X7R 0805 06352 C2012X7R1H104K
C1108 - C1117 0160-5944 CAP-FXD 0.047uF +-10% 50 V CER X7R 02010 08055C473KAT A
C1118 0160-5945 C MLYS .01U 50V CAP. 02010 08055C103KAT A
C1119 0160-5944 CAP-FXD 0.047uF +-10% 50 V CER X7R 02010 08055C473KAT A
C1120 - C1126 0160-7798 CAP 0.1UF 50V 10% X7R 0805 06352 C2012X7R1H104K
C1201 0180-4538 CAP-FXD 100uF +-20% 10 V TA 12340 T495X107M010AS
C1202 - C1219 0160-7798 CAP 0.1UF 50V 10% X7R 0805 06352 C2012X7R1H104K
C1220 0160-7736 CAP-FXD 1uF +-10% 16 V CER X7S 06352 C3216X7R1C105K
C1301 - C1329 0160-7798 CAP 0.1UF 50V 10% X7R 0805 06352 C2012X7R1H104K
C1401 - C1426 0160-7798 CAP 0.1UF 50V 10% X7R 0805 06352 C2012X7R1H104K
C1501 0160-5945 C MLYS .01U 50V CAP. 02010 08055C103KAT A
C1502 0160-7736 CAP-FXD 1uF +-10% 16 V CER X7S 06352 C3216X7R1C105K
C1503 0160-5945 C MLYS .01U 50V CAP. 02010 08055C103KAT A
C1504 0180-4577 CAP-FXD 10uF +-20% 10 V TA 12340 T491B106M010AS
C1505 0160-7798 CAP 0.1UF 50V 10% X7R 0805 06352 C2012X7R1H104K
C1506 0160-7736 CAP-FXD 1uF +-10% 16 V CER X7S 06352 C3216X7R1C105K
C1507 0160-5945 C MLYS .01U 50V CAP. 02010 08055C103KAT A
C1508 0160-5976 2 CAP-FXD 12pF 50 V 02010 08051A120JAT A
C1509 0160-5945 C MLYS .01U 50V CAP. 02010 08055C103KAT A
Reference
Designator
Agilent Part
Number
Qty Part Description
Mfr.
Code
Mfr. Part Number
To Next Page
