156
Chapter 7 Replaceable Parts
33250-66511 – Main PC Assembly (A1)
7
C1510 0160-7798 CAP 0.1UF 50V 10% X7R 0805 06352 C2012X7R1H104K
C1511 0160-7722 4 CAP-FXD 39pF +-1% 50 V CER C0G 02010 08055A390FATMA
C1512 0160-7708 CAP 1000pF 50 V 02010 08055A102JATRA
C1513 0160-7736 CAP-FXD 1uF +-10% 16 V CER X7S 06352 C3216X7R1C105K
C1514 0160-5952 CAP-FXD 330pF +-5% 50 V CER C0G 02010 08055A331JAT A
C1515 0160-5967 CF 100PF 5% 06352 C2012COG1H101J
C1516 - C1522 0160-7798 CAP 0.1UF 50V 10% X7R 0805 06352 C2012X7R1H104K
C1523 0160-7736 CAP-FXD 1uF +-10% 16 V CER X7S 06352 C3216X7R1C105K
C1524 - C1531 0160-7798 CAP 0.1UF 50V 10% X7R 0805 06352 C2012X7R1H104K
C1532 0160-7736 CAP-FXD 1uF +-10% 16 V CER X7S 06352 C3216X7R1C105K
C1533 0160-7798 CAP 0.1UF 50V 10% X7R 0805 06352 C2012X7R1H104K
C1601 0160-7798 CAP 0.1UF 50V 10% X7R 0805 06352 C2012X7R1H104K
C1602 0180-4559 2 CAP-FXD 68uF +-20% 10 V TA 12340 T491D686M010AS
C1603 0160-8361 CAP 0.22UF 25 V 06352 C2012X7R1E224K
C1604 0160-7798 CAP 0.1UF 50V 10% X7R 0805 06352 C2012X7R1H104K
C1605 0160-6444 CAP-FXD 0.022uF 50 V 02010 08055C223KAT
C1606 - C1607 0160-7798 CAP 0.1UF 50V 10% X7R 0805 06352 C2012X7R1H104K
C1610 0160-5956 2 CAP-FXD 56pF 50 V 02010 08055A560JAT A
C1611 0160-6102 1 CAT008 CAP,CER,CHIP 02010 12065A152JATRA
C1612 0160-7940 1 CAP-FXD 0.027uF +-10% 50 V CER X7R 02010 08055C273KATA
C1613 0160-8779 1 CAP .056UF 50V 10% COG 1206 12340 C1206C564K4RAC
C1615 0160-7798 CAP 0.1UF 50V 10% X7R 0805 06352 C2012X7R1H104K
C1616 0160-6444 CAP-FXD 0.022uF 50 V 02010 08055C223KAT
C1617 0160-5942 1 CAP-FXD 1pF 50 V 02010 08051A1R0CAT A
C1618 0160-7798 CAP 0.1UF 50V 10% X7R 0805 06352 C2012X7R1H104K
C1619 0160-8361 CAP 0.22UF 25 V 06352 C2012X7R1E224K
C1620 0160-7798 CAP 0.1UF 50V 10% X7R 0805 06352 C2012X7R1H104K
C1621 0180-4559 CAP-FXD 68uF +-20% 10 V TA 12340 T491D686M010AS
C1622 - C1625 0160-7798 CAP 0.1UF 50V 10% X7R 0805 06352 C2012X7R1H104K
C1701 0160-8279 2 CAP 2.7PF 50V +1-0.05PF COG 0805 02010 08055A2R7CATA
C1702 0160-5962 3 CAP-FXD 15pF +-5% 50 V CER C0G 09939 GRM40C0G150J050
C1703 0160-5961 FIXED CAPACITOR; 22PF 50 VOLTS 02010 08055A220JAT A
C1704 0160-5975 CAP-FXD 10pF 50 V 02010 08055A100JAT A
C1705 0160-5962 CAP-FXD 15pF +-5% 50 V CER C0G 09939 GRM40C0G150J050
C1707 0160-7757 CAP-FXD 47pF +-1% 50 V CER C0G 02010 08055A470FATMA
C1708 0160-5969 2 CAPACITOR, FIXED CERAMIC CHIP 02010 08051A3R3CAT A
C1709 0160-7722 CAP-FXD 39pF +-1% 50 V CER C0G 02010 08055A390FATMA
C1710 0160-5970 1 CAP-FXD 3.9pF 50 V 06352 C2012COG1H3R9C
C1711 0160-7722 CAP-FXD 39pF +-1% 50 V CER C0G 02010 08055A390FATMA
C1712 0160-8280 1 CAP-FXD 4.7PF +-5% 50 V CER COG 02010 08055A4R7CATA
C1713 0160-5975 CAP-FXD 10pF 50 V 02010 08055A100JAT A
C1714 0160-5976 CAP-FXD 12pF 50 V 02010 08051A120JAT A
C1716 - C1717 0160-7798 CAP 0.1UF 50V 10% X7R 0805 06352 C2012X7R1H104K
C1718 0160-7324 1 CAP-FXD 120pF 50 V 02010 08055A121FATMA
C1719 0160-5975 CAP-FXD 10pF 50 V 02010 08055A100JAT A
Reference
Designator
Agilent Part
Number
Qty Part Description
Mfr.
Code
Mfr. Part Number
To Next Page
