42 34410A/11A User’s Guide
2 Features and Functions
Second Display Options
Four measurement functions have an auxiliary measurement that can be
displayed in parallel on the second display line, as follows:
• Front Panel Operation: To enter the second display menu for the selected
measurement function, press . Then press or to select the
desired second display option, and press . Once the second display
is enabled, you can always scroll through the available display options,
including STATS or LIMITS if these Math functions are enabled.
• Remote Interface Operation: The following command selects the
measurement or math function to be displayed on the second display
line. The <feed> parameter is a quoted ASCII string designating the
function to be displayed, such as VOLTage:PTPeak.
DISPlay:WINDow2: TEXT:FEED <feed>
The following query returns the currently selected <feed> parameter,
as a quoted ASCII string:
DISPlay:WINDow2: TEXT:FEED?
Refer to the Agilent 34410A/34411A Programmer’s Reference for
complete description and syntax for these commands.
Turning the Display Off
This feature is available from the remote interface only.
For security reasons, you may wish to disable the front panel display.
When disabled, the entire front panel display (except for the Error and
Remote annunciators) goes dark.
• Remote Interface Operation: The following command disables the front
panel display:
DISP OFF
The following command queries the front panel display setting:
DISP?
The query returns a “0” (OFF) or “1” (ON).
Refer to the Agilent 34410A/34411A Programmer’s Reference for
complete description and syntax for these commands.
Primary Function Dual Measurement Option
DC V, DC I Peak–to–Peak value*
FREQ AC Voltage**
TEMP Raw Resistance***
*largest spike measured during reading integration
**ac voltage of the input waveform
***actual raw resistance measured across temperature probe and leads
