34410A/11A User’s Guide 75
Features and Functions 2
The following tables list the automatic trigger delays for ac measurements,
triggered from the remote interface. From the front panel, assume an
automatic trigger delay of 50 ms for all ac measurements.
AC Voltage Measurements (all ranges):
AC Current Measurements (all ranges):
Frequency and Period
Temperature measurements actually use the 2–wire or 4–wire resistance
functions. The above tables for resistance apply to temperature
measurements, but all temperature measurements use autoranging. Since
the range in use cannot be predicted, nor can the delay. Use the
TRIGger:DELay? command to show the actual trigger delay.
Capacitance measurements have a trigger delay of zero, because
discharging the capacitor is part of the measurement time.
AC Filter Trigger Delay
Slow (3 Hz) 2.5 sec
Medium (20 Hz) 625 ms
Fast (200 Hz) 25 ms
AC Filter Trigger Delay
Slow (3 Hz) 1.66 sec
Medium (20 Hz) 250 ms
Fast (200 Hz) 25 ms
Trigger Delay
1 sec
