Agilent Technologies 7683 - Using The Optional 100-vial Tray

Operation Guide
Preparing Sample Vials
12
Figure 5 Vial placement in the turret
If You Use The Optional 100-vial Tray
You must use the standard turret. You may place up to 100 samples in the
four-tray quadrants, according to the programmed sequence. Figure 6 shows
sample vials placed in a tray for a sequence that uses tray positions 6 through 21.
Figure 6 Loading tray positions
8 position turret
*Requires optional insert (part no. 07673-40150) to hold sample vial.
Sample 1
Solvent A
Solvent B
Waste
Sample 8
Sample 1
Waste B or (Sample 3*)
Solvent A
Waste A
Solvent B
Standard turret
Solvent B2
(or Sample 2*)
Last bottle in position 21
First bottle in
position 6
5
15
2
0
1
0
2
5
1
