Front Panel Overview Introduction to the Agilent 81133A/81134A Pulse Generator
Agilent 81133A/81134A Pulse Generator User’s Guide, August 2002 15
Front Panel Overview
The following figure shows the main elements of the front panel.
The front panel has the following elements:
• Graphical User Interface
The graphical user interface is used for monitoring (and changing)
the instrument’s settings
•Softkeys
The softkeys provide context-sensitive functions (functionality
changes according to requirements)
•Numeric keys
Used to set parameter values.
•Tab keys
Used to scroll through the pages of the graphical user interface.
• Navigation knob
Used to navigate through and to change parameter values in an easy
way, and also for navigating through the online help.
For more information, see “Operating the Agilent 81133A/81134A
Pulse Generator” on page 19.
•Inputs and Outputs
The instrument provides global and channel-specific inputs and
outputs as described in the following section.
Tab Keys to navigate
between the pages
Navigation knob
Softkeys Inputs and outputsGraphical User
Interface
Numeric
Keys
