Jitter Modulation Using the Agilent 81133A/81134A Pulse Generator
Agilent 81133A/81134A Pulse Generator User’s Guide, August 2002 83
Jitter Modulation
The external source for jitter modulation is applied to the delay
control input. Jitter modulation can be turned on and off individually
for each channel. Either one of two fixed sensitivities can be selected.
The source for the jitter modulation input is assumed to be either a
function generator or an arbitrary waveform generator. Both have the
capability of setting the output levels. Therefore, the instrument has no
capabilities of adjusting the jitter modulation input.
Saving and Recalling Settings
For permanently saving the instrument setting, nine save/recall
registers are provided.
All parameters are saved, including the data. User interface specifics,
such as the current visible page, are not saved.
When the instrument is turned on, the last used setting is restored.
