Setting Up Generic and Advanced Signals Setting Up a Clock Signal
28 Agilent 81133A/81134A Pulse Generator User’s Guide, August 2002
Setting Up a Clock Signal
Tas k Set up two clock signals with 100 MHz and 200 MHz frequencies, a
duty cycle of 50%, a high level of 1.0 V and a low level of 0 V.
Use Cases Generating clock signals can be used for:
•Boards evaluation
•Microprocessors
•A/D Converters
• PCI/PCI-X validation
• Digital ASIC design for high-speed HDD
f = 200 MHz
0.0 V
1.0 V
Duty Cycle = 50%
f = 100 MHz
0.0 V
1.0 V
Duty Cycle = 50%
