Pages of the User Interface Using the Agilent 81133A/81134A Pulse Generator
Agilent 81133A/81134A Pulse Generator User’s Guide, August 2002 67
• Data Page
At the Data page, you can set up an arbitrary data pattern up to the
maximal available memory (8 kBit) per channel.
•Aux Page
The Aux page provides controls to specify:
– The Clock Source
–The Start Input
– The Trigger Output
• Config Page
If you want to program the instrument remotely, the Config page is
used to set up all necessary parameters to establish the connection
between the instrument and your control PC.
To access the individual pages, use the instrument's tab keys (located
below the navigation knob).
NOTE For a detailed description of the pages and their parameters, please
refer to the Online Help.
