20 Agilent Gas Sample Selector for 8860 and 8890 User Manual
2 Introduction
Gas Sample Selector bag version
Figure 4 Gas Sample Selector bag version, rear view.
GC to Selector
connection
(bag version only)
Selector to GC
connection
Vent
(bag version only)
Air/N
2
3.8 bar
(55 psi)
Purge gas, air/N
2
25 bar MAX
(363 psi)
Purge flow
Sample flow
USB COM
connection
Power
connection
(24 VDC, 90 W)
