Installation 3
Site Preparation
Agilent Gas Sample Selector for 8860 and 8890 Safety and Installation Manual 45
Site Preparation
NOTE
It is recommended that the capacity of the sampling gas cylinder be less than
500 cc. Choose a suitable capacity of 100 to 500 cc.
• Leave enough space on the left side of the GC to place the cylinder version
selector (40 cm).
• Installation requires 1 power outlet.
Other materials required (not provided):
• 1/8-inch tubing, terminating in a 1/8-inch male Swagelok fitting, that is long
enough to connect the Selector sample exhaust vent to the laboratory exhaust
system or fume hood.
• Compressed air supply, terminating in a 1/8-inch male Swagelok connector
(for valve actuation) at 380 kPa (55 psi).
• Purge gas supply, nitrogen, air, or helium, terminating in a 1/8-inch male
Swagelok connector.
• Sample cylinders must use a 1/4-inch Male NPT fitting. (The Selector includes
female 1/4-inch NPT fittings.)
Tools required
• 7/16-inch wrench
• 1/4-inch wrench
• Adjustable wrench
• PTFE tape
• Swagelok male connectors (8 sets) matched with 1/4-inch Swagelok NPT
female fittings.
NOTE
For the Swagelok quick connectors, the following are recommended:
• 1/4-inch Swagelok NPT female connector,
Swagelok part number SS-400-71-4
• Swagelok part number SS-QTM2A-B-4PM (Male)
• Swagelok part number SS-QTM2-D-4PM (Male)
