Agilent Technologies B1500A User Manual

3-8 Agilent B1500 VXIplug&play Driver User’s Guide, Edition 3
Programming Examples for Visual Basic Users
High Speed Spot Measurement
Sub spot_meas(vi As Long, ret As Long, pins() As Long) ’1
Dim vd As Double ’3
Dim vg As Double
Dim idcomp As Double
Dim igcomp As Double
Dim meas As Double
Dim status As Long
vd = 0.5
idcomp = 0.05
vg = 0.5
igcomp = 0.01 ’12
ret = agb1500_force(vi, pins(3), agb1500_VF_MODE, 0, 0, 0.05, 0) ’14
ret = agb1500_force(vi, pins(2), agb1500_VF_MODE, 0, 0, 0.05, 0)
ret = agb1500_force(vi, pins(1), agb1500_VF_MODE, 2, vg, igcomp, 0)
ret = agb1500_force(vi, pins(0), agb1500_VF_MODE, 2, vd, idcomp, 0) ’17
check_err vi, ret
ret = agb1500_spotMeas(vi, pins(0), agb1500_IM_MODE, 0, meas, status, 0) ’20
check_err vi, ret
ret = agb1500_zeroOutput(vi, agb1500_CH_ALL) ’22
check_err vi, ret
display_data meas, status, vi, ret, pins()
End Sub
Line Description
1 Beginning of the spot_meas subprogram.
3 to 12 Declares variables, and defines the value.
14 to 17 Applies voltage to device.
20 Performs the high speed spot measurement.
22 Sets the specified port to the zero output state.
18, 21, and 23 Calls the check_err subprogram (shown in Table 3-1) to check if an error status is
returned for the previous line.
25 Calls the display_data subprogram (next page) to display measurement data.
26 End of the spot_meas subprogram.

Agilent Technologies B1500A Specifications

General

Type	Semiconductor Device Analyzer
Model	B1500A
Maximum Voltage	200 V
Number of SMUs	Up to 10
Frequency Range	DC to 1 MHz
Connectivity	USB, LAN
Channels	Up to 10
Interface	GUI

Summary

Installation

System Requirements

Details the necessary hardware and software for the driver.

Installing VXIplug&play Driver

Provides a step-by-step guide for installing the driver.

Before Programming

Covers pre-programming setup and configuration steps.

Driver Functions

Function List

Lists all available driver functions with brief descriptions.

Parameters

Details the parameters used by various driver functions.

Status Code

Describes the status codes returned by measurement functions.

Function Reference

Provides detailed descriptions and syntax for each driver function.

Visual Basic Programming Examples

Programming Basics

Basic information and steps for programming with the driver.

High Speed Spot Measurement Example

Example demonstrating high-speed spot measurement using Visual Basic.

Staircase Sweep Measurement Example

Example for staircase sweep measurements.

Breakdown Voltage Measurement Example

Example for measuring breakdown voltage.

Leakage Current Measurement Example

Example for measuring leakage current.

C++ Programming Examples

Programming Basics

Basic information and steps for C++ programming.

High Speed Spot Measurement Example

Example demonstrating high-speed spot measurement in C++.

Staircase Sweep Measurement Example

Example for staircase sweep measurements in C++.

Breakdown Voltage Measurement Example

Example for measuring breakdown voltage in C++.

Leakage Current Measurement Example

Example for measuring leakage current in C++.

Sampling Measurement Example

Example for sampling measurement in C++.

CV Sweep Measurement Example

Example for CV sweep measurement in C++.
