Agilent B1500 VXIplug&play Driver User’s Guide, Edition 3 4-5
Programming Examples for C++ Users
Programming Basics
/* Starting the session */
ret = agb1500_init("GPIB0::17::INSTR", VI_TRUE, VI_TRUE, &vi); /* 33 */
if ( ( ret < VI_SUCCESS ) || ( vi == VI_NULL ) ) {
printf("Initialization failure.\n Status code: %d.\n", ret);
if ( vi != VI_NULL ) {
agb1500_error_message(vi, ret, err_msg);
printf("Error: %ld\n %s\n", ret, err_msg);
}
exit (ret);
} /* 41 */
ret = agb1500_reset(vi); /* resets B1500 43 */
ret = agb1500_timeOut(vi, 60000); /* sets 60 second timeout */
ret = agb1500_errorQueryDetect(vi, VI_TRUE); /* turns on error detection */
perform_meas(vi, ret); /* calls perform_meas subprogram 47 */
/* ret = agb1500_cmd(vi, "aa"); sends an invalid command */
/* check_err(vi, ret); checks check_err subprogram operation */
/* Closing the session
ret = agb1500_close(vi); 52 */
check_err(vi, ret);
return VI_SUCCESS; /* 55 */
}
Line Description
33 Establishes the software connection with the Agilent B1500.
The above example is for the Agilent B1500 on the GPIB address 17.
Confirm the GPIB address of your B1500, and set the address correctly instead of “17”.
34 to 41 Checks the status returned by the agb1500_init function. Displays the error message
and stops the program execution if an error status is returned.
43 to 45 Resets the Agilent B1500, sets the driver I/O time out to 60 seconds, and enables the
automatic instrument error checking.
47 Calls the perform_meas subprogram (line 22).
48 to 49 Should be deleted or commented out before executing the program. The lines are just
used to check the operation of the check_err subprogram.
52 Disables the software connection with the Agilent B1500.
53 Calls the check_err subprogram to check if an error status is returned for the line 52.
55 to 56 End of the main program.

Agilent Technologies B1500A Specifications

General

Type	Semiconductor Device Analyzer
Model	B1500A
Maximum Voltage	200 V
Number of SMUs	Up to 10
Frequency Range	DC to 1 MHz
Connectivity	USB, LAN
Channels	Up to 10
Interface	GUI

Summary

Installation

System Requirements

Details the necessary hardware and software for the driver.

Installing VXIplug&play Driver

Provides a step-by-step guide for installing the driver.

Before Programming

Covers pre-programming setup and configuration steps.

Driver Functions

Function List

Lists all available driver functions with brief descriptions.

Parameters

Details the parameters used by various driver functions.

Status Code

Describes the status codes returned by measurement functions.

Function Reference

Provides detailed descriptions and syntax for each driver function.

Visual Basic Programming Examples

Programming Basics

Basic information and steps for programming with the driver.

High Speed Spot Measurement Example

Example demonstrating high-speed spot measurement using Visual Basic.

Staircase Sweep Measurement Example

Example for staircase sweep measurements.

Breakdown Voltage Measurement Example

Example for measuring breakdown voltage.

Leakage Current Measurement Example

Example for measuring leakage current.

C++ Programming Examples

Programming Basics

Basic information and steps for C++ programming.

High Speed Spot Measurement Example

Example demonstrating high-speed spot measurement in C++.

Staircase Sweep Measurement Example

Example for staircase sweep measurements in C++.

Breakdown Voltage Measurement Example

Example for measuring breakdown voltage in C++.

Leakage Current Measurement Example

Example for measuring leakage current in C++.

Sampling Measurement Example

Example for sampling measurement in C++.

CV Sweep Measurement Example

Example for CV sweep measurement in C++.
