Agilent B1500 VXIplug&play Driver User’s Guide, Edition 3 2-43
Driver Functions
agb1500_scuuLed
agb1500_scuuLed
This function is available for the Agilent B1500 installed with the multi frequency
capacitance measurement unit (MFCMU) and the SMU CMU unify unit (SCUU).
To use the SCUU, connect it to the MFCMU and two SMUs (MPSMU or HRSMU)
correctly. The SCUU cannot be used with the HPSMU or when only one SMU is
connected.
This function enables or disables the connection status indicator of the SCUU.
Syntax ViStatus _VI_FUNC agb1500_scuuLed(ViSession vi, ViInt32 channel,
ViInt32 mode)
Parameters vi Instrument handle returned from agb1500_init( ).
channel Slot number where the MFCMU has been installed. The SCUU
must be connected to the MFCMU. See Table 2-2. channel=-1
detects the slot automatically.
mode 0: Disables the indicator.
1: Enables the indicator. Initial setting.
NOTE To use SCUU
Before turn the Agilent B1500 on, connect the SCUU to the MFCMU and two
MPSMU/HRSMUs properly. The SCUU is used to switch the module (SMU or
MFCMU) connected to the DUT.
