Agilent Technologies B1500A User Manual

Agilent B1500 VXIplug&play Driver User’s Guide, Edition 3 3-15
Programming Examples for Visual Basic Users
Pulsed Spot Measurement
Sub spot_meas(vi As Long, ret As Long, pins() As Long) ’1
Dim vd As Double ’3
Dim vg As Double
Dim idcomp As Double
Dim igcomp As Double
Dim meas As Double
Dim status As Long
vd = 0.5
idcomp = 0.05
vg = 0.5
igcomp = 0.01 ’12
Dim base As Double ’14
Dim width As Double
Dim period As Double
Dim hold As Double
base = 0
width = 0.001
period = 0.01
hold = 0.1 ’21
ret = agb1500_setFilter(vi, pins(1), agb1500_FLAG_OFF) ’23
ret = agb1500_setPbias(vi, pins(1), agb1500_VF_MODE, 2, base,
vg, width, period, hold, igcomp)
ret = agb1500_force(vi, pins(3), agb1500_VF_MODE, 0, 0, 0.05, 0)
ret = agb1500_force(vi, pins(2), agb1500_VF_MODE, 0, 0, 0.05, 0)
ret = agb1500_force(vi, pins(0), agb1500_VF_MODE, 2, vd, idcomp,
0)
check_err vi, ret ’29
Line Description
1 Beginning of the spot_meas subprogram.
3 to 12 Declares variables for the dc sources, and defines the value.
14 to 21 Declares variables for the pulsed source, and defines the value.
23 to 24 Sets SMU filter off for the pulsed bias channel, and sets the
pulsed bias source.
25 to 27 Applies voltage to device.
29 Calls the check_err subprogram (shown in Table 3-1) to check if
an error status is returned for the previous line.

Agilent Technologies B1500A Specifications

General

Type	Semiconductor Device Analyzer
Model	B1500A
Maximum Voltage	200 V
Number of SMUs	Up to 10
Frequency Range	DC to 1 MHz
Connectivity	USB, LAN
Channels	Up to 10
Interface	GUI

Summary

Installation

System Requirements

Details the necessary hardware and software for the driver.

Installing VXIplug&play Driver

Provides a step-by-step guide for installing the driver.

Before Programming

Covers pre-programming setup and configuration steps.

Driver Functions

Function List

Lists all available driver functions with brief descriptions.

Parameters

Details the parameters used by various driver functions.

Status Code

Describes the status codes returned by measurement functions.

Function Reference

Provides detailed descriptions and syntax for each driver function.

Visual Basic Programming Examples

Programming Basics

Basic information and steps for programming with the driver.

High Speed Spot Measurement Example

Example demonstrating high-speed spot measurement using Visual Basic.

Staircase Sweep Measurement Example

Example for staircase sweep measurements.

Breakdown Voltage Measurement Example

Example for measuring breakdown voltage.

Leakage Current Measurement Example

Example for measuring leakage current.

C++ Programming Examples

Programming Basics

Basic information and steps for C++ programming.

High Speed Spot Measurement Example

Example demonstrating high-speed spot measurement in C++.

Staircase Sweep Measurement Example

Example for staircase sweep measurements in C++.

Breakdown Voltage Measurement Example

Example for measuring breakdown voltage in C++.

Leakage Current Measurement Example

Example for measuring leakage current in C++.

Sampling Measurement Example

Example for sampling measurement in C++.

CV Sweep Measurement Example

Example for CV sweep measurement in C++.
