3-20 Agilent B1500 VXIplug&play Driver User’s Guide, Edition 3
Programming Examples for Visual Basic Users
Staircase Sweep Measurement
ret = agb1500_resetTimestamp(vi) ’45
check_err vi, ret
ret = agb1500_force(vi, m(3), agb1500_VF_MODE, 0, 0, 0.05, 0)
ret = agb1500_force(vi, m(2), agb1500_VF_MODE, 0, 0, 0.05, 0)
Dim d_vg As Double ’secondary sweep step value (delta) ’51
If nop2 = 1 Then
d_vg = 0
Else
d_vg = (vg2 - vg1) / (nop2 - 1)
End If ’56
Dim vg As Double ’secondary sweep source output ’58
vg = vg1
i = 0 ’array counter for sweepIv returned data ’61
Line Description
45 Resets time stamp.
46 Calls the check_err subprogram (shown in Table 3-1) to check if
an error status is returned for the previous line.
48 to 49 Applies voltage to device.
51 to 56 Declares a variable, and defines the value. This variable is used
for the step value of the secondary sweep source.
58 to 59 Declares a variable, and defines the value. This variable is used
for the output value of the secondary sweep source.
61 Sets the array counter i to 0.

Agilent Technologies B1500A Specifications

General

Type	Semiconductor Device Analyzer
Model	B1500A
Maximum Voltage	200 V
Number of SMUs	Up to 10
Frequency Range	DC to 1 MHz
Connectivity	USB, LAN
Channels	Up to 10
Interface	GUI

Summary

Installation

System Requirements

Details the necessary hardware and software for the driver.

Installing VXIplug&play Driver

Provides a step-by-step guide for installing the driver.

Before Programming

Covers pre-programming setup and configuration steps.

Driver Functions

Function List

Lists all available driver functions with brief descriptions.

Parameters

Details the parameters used by various driver functions.

Status Code

Describes the status codes returned by measurement functions.

Function Reference

Provides detailed descriptions and syntax for each driver function.

Visual Basic Programming Examples

Programming Basics

Basic information and steps for programming with the driver.

High Speed Spot Measurement Example

Example demonstrating high-speed spot measurement using Visual Basic.

Staircase Sweep Measurement Example

Example for staircase sweep measurements.

Breakdown Voltage Measurement Example

Example for measuring breakdown voltage.

Leakage Current Measurement Example

Example for measuring leakage current.

C++ Programming Examples

Programming Basics

Basic information and steps for C++ programming.

High Speed Spot Measurement Example

Example demonstrating high-speed spot measurement in C++.

Staircase Sweep Measurement Example

Example for staircase sweep measurements in C++.

Breakdown Voltage Measurement Example

Example for measuring breakdown voltage in C++.

Leakage Current Measurement Example

Example for measuring leakage current in C++.

Sampling Measurement Example

Example for sampling measurement in C++.

CV Sweep Measurement Example

Example for CV sweep measurement in C++.
