Agilent B1500 VXIplug&play Driver User’s Guide, Edition 3 3-27
Programming Examples for Visual Basic Users
Staircase Sweep Measurement
Sub save_data(nop As Long, md() As Double, st() As Long, sc() As Double, tm() As
Double, vi As Long, ret As Long, m() As Long) ’1
Dim i As Integer ’array counter for primary sweep ’3
Dim val As String ’data to be saved to a file
val = "Vg (V), Id (mA), Time (sec), Status"
For i = 0 To nop - 1 ’7
val = val & Chr(13) & Chr(10) & sc(i) & "," & md(i) * 1000 & "," & tm(i) & "," &
st(i)
Next i
Dim fname As String ’data file name ’11
Dim fnum As Integer ’file number
fname = "C:\Agilent\mdata\data2.txt"
fnum = 1
’saves data into the file specified by fname
Open fname For Output Access Write Lock Read Write As fnum
Print #fnum, val
Close fnum
’displays data on a MsgBox
Dim title As String ’21
Dim rbx As Integer
title = "Sweep Measurement Result"
val = val & Chr(10) & Chr(10) & "Data save completed."
val = val & Chr(10) & Chr(10) & "Do you want to perform measurement again?"
rbx = MsgBox(val, vbYesNo, title)
If rbx = vbYes Then
sweep_meas vi, ret, m() ’returns to sweep_meas if Yes is clicked.
End If ’29
End Sub
Line Description
1 Beginning of the save_data subprogram.
3 to 5 Declares variables, and defines the value.
7 to 9 Creates data to be saved and displayed on a message box.
11 to 19 Saves measurement data into a CSV file specified by the fname variable.
21 to 29 Displays measurement data on a message box. If Yes is clicked on the message
box, performs the sweep_meas subprogram again. If No is clicked, returns to the
perform_meas subprogram.
31 End of the save_data subprogram.
