Agilent Technologies B1500A User Manual

4-10 Agilent B1500 VXIplug&play Driver User’s Guide, Edition 3
Programming Examples for C++ Users
Multi Channel Spot Measurement
Measurement
Result Example
Ic = 3.846500 mA (Time: 0.093200 sec)
Ib = 0.018970 mA (Time: 0.094300 sec)
hfe = 202.767528
mch[0] = collector; /* 31 */
mch[1] = base;
mch[2] = 0;
mode[0] = 1;
mode[1] = 1;
range[0] = 0;
range[1] = 0;
ret = agb1500_resetTimestamp(vi); /* 38 */
ret = agb1500_force(vi, emitter, agb1500_VF_MODE, 0, 0, 0.2, 0);
ret = agb1500_force(vi, base, agb1500_VF_MODE, 0, vb, ibcomp, 0);
ret = agb1500_force(vi, collector, agb1500_VF_MODE, 0, vc, iccomp, 0);
check_err (vi, ret); /* 42 */
ret = agb1500_measureM(vi, mch, mode, range, &md[0], &st[0], &tm[0]);
check_err (vi, ret); /* 45 */
ret = agb1500_zeroOutput(vi, agb1500_CH_ALL); /* 47 */
check_err (vi, ret); /* 48 */
printf("Ic = %8.6f mA (Time: %8.6f sec)\n", md[0] * 1000, tm[0]);
printf("Ib = %8.6f mA (Time: %8.6f sec)\n", md[1] * 1000, tm[1]);
printf("hfe = %10.6f \n", md[0]/md[1]); /* 52 */
ret = agb1500_setSwitch(vi, agb1500_CH_ALL, 0); /* 54 */
check_err (vi, ret); /* 55 */
}
Line Description
31 to 37 Defines the value for the variables used for the measurement channel.
38 Resets time stamp.
39 to 41 Applies voltage to device.
44 Performs multi channel spot measurement.
47 Sets the specified port to the zero output state.
50 to 52 Displays the measurement result data.
54 Disables all ports.
42, 45, 48 and 55 Calls the check_err subprogram (shown in Table 4-1) to check if an error status is
returned for the previous line.
56 End of the perform_meas subprogram.

Agilent Technologies B1500A Specifications

General

Type	Semiconductor Device Analyzer
Model	B1500A
Maximum Voltage	200 V
Number of SMUs	Up to 10
Frequency Range	DC to 1 MHz
Connectivity	USB, LAN
Channels	Up to 10
Interface	GUI

Summary

Installation

System Requirements

Details the necessary hardware and software for the driver.

Installing VXIplug&play Driver

Provides a step-by-step guide for installing the driver.

Before Programming

Covers pre-programming setup and configuration steps.

Driver Functions

Function List

Lists all available driver functions with brief descriptions.

Parameters

Details the parameters used by various driver functions.

Status Code

Describes the status codes returned by measurement functions.

Function Reference

Provides detailed descriptions and syntax for each driver function.

Visual Basic Programming Examples

Programming Basics

Basic information and steps for programming with the driver.

High Speed Spot Measurement Example

Example demonstrating high-speed spot measurement using Visual Basic.

Staircase Sweep Measurement Example

Example for staircase sweep measurements.

Breakdown Voltage Measurement Example

Example for measuring breakdown voltage.

Leakage Current Measurement Example

Example for measuring leakage current.

C++ Programming Examples

Programming Basics

Basic information and steps for C++ programming.

High Speed Spot Measurement Example

Example demonstrating high-speed spot measurement in C++.

Staircase Sweep Measurement Example

Example for staircase sweep measurements in C++.

Breakdown Voltage Measurement Example

Example for measuring breakdown voltage in C++.

Leakage Current Measurement Example

Example for measuring leakage current in C++.

Sampling Measurement Example

Example for sampling measurement in C++.

CV Sweep Measurement Example

Example for CV sweep measurement in C++.
